KNE0302

1.    Electrical Data

       A.     Frequency Range ---- DC-6GHz

       B.     Impedance---- 50 Ohms

       C.     VSWR---- < 1.2

       D.     Insertion loss -----  0.5 dB max (DC -6GHz)

       E.      Dielectric withstanding voltage ---- 500 Vrms

       F.      Insulation resistance ---- 1000 Mega-Ohms

       G.     Center contact resistance ---- 10.0 mini-Ohms

       H.     Outer contact resistance---- 6.0 mini-Ohms

2.    Mechanical Data

       A.     Coupling Method — Threaded

       B.     Durability (Mating / Unmating ) : 10000  cycles for RSWU.FL

       C.     Durability (Mating / Unmating ) : 500  cycles for SMPM

       D.     Temperature Range : -40° ~ 90°
